LONGWELL, nrog dhau 20 xyoo kev, yog ib qho loj tshaj plaws Auto Vacuum EPS cornice moulding tshuab chaw tsim tshuaj paus thiab cov muag khoom hauv Suav teb. Nrog kev pab ntawm cov cuab yeej siv siab tshaj thiab thev naus laus zis, txhua yam ntawm peb cov khoom yog cov siab zoo thiab tsis tshua muaj nqi. Txais tos kom yuav lub tshuab pheej yig customized los ntawm peb lub hoobkas.
Cov Kab Ntau Lawm
Lub ntsiab kom zoo dua:
1. Tswj los ntawm PLC thiab kov npo, yooj yim rau kev khiav lag luam.
2. Nrog lub tshuab nqus tsev tsim cov khoom lag luam nrawm nrawm nrawm thiab txias, thaum lub sijhawm dej tsawg.
3. Nrog ntau hom de-molding cuab yeej, nws tuaj yeem daws txhua qhov nyuaj rau de-puab cov khoom.
Cov yam ntxwv:
1. Tswj los ntawm PLC thiab kov npo, yooj yim rau kev khiav lag luam.
2. Txhua tus qauv yog pib nrog kev kho cua sov.
3. Nrog lub tshuab nqus tsev tsim cov khoom lag luam nrawm nrawm nrawm thiab txias, thaum lub sijhawm dej tsawg.
4. Nrog ntau cov cuab yeej de-molding, nws tuaj yeem daws txhua yam khoom nyuaj-rau-de-pwm .
5. Nrog sawv ntsug rau lub tshuab, tsis tas yuav tsim cov txheej txheem ntxiv rau cov khoom siv.
Daim ntawv npe tseem ceeb (peb tuaj yeem hloov seem raws li cov neeg siv khoom yuav tsum tau)
- Kov npo: Weinview lossis Delta , Taiwan
- PLC- Mitsubishi, Nyiv lossis Delta , Taiwan
- Chav lub kaum ntse ntse lub rooj sib tw: ESG, Lub Tebchaws Denmark
- Chav ntsuas - Afriso, Lub teb chaws Yelemees
- Tus Hu Xov Tooj: Schneider, Fab Kis
- Nruab Nrab Relay: Omron, Nyiv
- Hrdraulic chaw nres tsheb: Yuken , Taiwan
- Solenoid li qub: Burkert, Lub teb chaws Yelemees
- Lub tshuab nqus tsev twj tso kua mis: YHZBK
Yam khoom | LWS-1200B | LWS-1400B | LWS-1600B | LWS-1750B | LWS-2200B | |
Pwm Qhov Loj (hli) | 1200 * 1000 | 1400 * 1200 | 1600 * 1350 | 1750 * 1450 | 2200 * 1350 | |
Max Ua Tau Loj (hli) | 1050 * 850 * 350 | 1200 * 1050 * 350 | 1400 * 1200 * 350 | 1550 * 1300 * 350 | 200 * 1200 * 350 | |
Mob stroke (hli) | 150 ~ 1350 | 150 ~ 1350 | 150 ~ 1350 | 150 ~ 1350 | 150 ~ 1350 | |
Ncu | Nkag | DN65 | DN80 | DN100 | DN100 | DN100 |
Qhov Tau Txais | 5 ~ 7kg / phaum | 6 ~ 9kg / phaum | 7 ~ 10kg / phaum | 8 ~ 12kg / phaum | 12 ~ 15kg / phaum | |
Siab | 0,5 ~ 0.7Mpa | 0,5 ~ 0.7Mpa | 0,5 ~ 0.7Mpa | 0,5 ~ 0.7Mpa | 0,5 ~ 0.7Mpa | |
Dej Txias | Nkag | DN65 | DN80 | DN80 | DN80 | DN80 |
Qhov Tau Txais | 45 ~ 130kg / phaum | 50 ~ 150kg / phaum | 55 ~ 170kg / phaum | 55 ~ 180kg / phaum | 60 ~ 190kg / phaum | |
Siab | 0.3 ~ 0.5Mpa | 0.3 ~ 0.5Mpa | 0.3 ~ 0.5Mpa | 0.3 ~ 0.5Mpa | 0.3 ~ 0.5Mpa | |
Ntshab Cua | Nkag | DN40 | DN50 | DN50 | DN50 | DN50 |
Qhov Tau Txais | 1.5m3 / phaum | 1.8 m3 / phaum | 2 m3 / phaum | 2 m3 / phaum | 2.5 m3 / phaum | |
Siab | 0,5 ~ 0.7Mpa | 0,5 ~ 0.7Mpa | 0,5 ~ 0.7Mpa | 0,5 ~ 0.7Mpa | 0,5 ~ 0.7Mpa | |
Lub tshuab nqus tsev muaj peev xwm | 165m3 / h | 230m3 / h | 280m3 / h | 280m3 / h | 280m3 / h | |
Lub sijhawm voj voog | 60 ~ 100s | 70 ~ 140s | 80 ~ 150s | 80 ~ 150s | 100 ~ 150s | |
Lub Zog | 10.6kw | 14.1kw | 16,5kw | 16,5kw | 20kw | |
Zuag qhia tag nrho qhov ntev (hli) | 4500 * 1840 * 2900 | 4600 * 2140 * 3100 | 5000 * 2300 * 3400 | 5000 * 2450 * 3500 | 5000 * 3000 * 3500 | |
Lub Tshuab hnyav | 4500kg | 5000kg | 5800kg | 6200kg | 7000kg | |
Ntim & Xa Khoom
Packing: txheem exporting pob
Thauj khoom: shanghai / ningbo
Kev pabcuam
1. Cov neeg muaj nuj nqis, lav cov khoom zoo thiab teb cov neeg siv cov lus nug txhua lub sijhawm thiab txhua qhov chaw.
2. Ua kho lub tshuab raws li cov neeg siv khoom nug, xws li cov qauv sib txawv, txawv cov khoom seem, cov xim sib txawv, ntau yam haujlwm, thiab lwm yam.
3. Cov kws tsim choj mus rau cov neeg siv khoom lub Hoobkas nyob rau lub sijhawm rau kev teeb tsa, kev cob qhia thiab kev sim khoom ntau lawm.
4. Muaj ntau cov khoom seem tau muab rau cov neeg siv khoom dawb los xyuas kom lub Hoobkas ua haujlwm yam tsis muaj dheev nres.
5. 1 xyoos lav dawb, Lub neej ua haujlwm pabcuam siab.
Yog tias koj txaus siab rau ib qho ntawm peb cov khoom lag luam lossis xav tau kev txhawb nqa los ntawm peb txog koj lub Hoobkas lossis lwm tus, thov koj xav tiv tauj peb. Peb tab tom nrhiav rau pem hauv ntej kom tsim kev lag luam ntev thiab kev sib raug zoo ua lag luam nrog cov neeg tau txais txiaj ntsig thoob plaws ntiaj teb.
