LONGWELL, nrog dhau 20 xyoo dhau los, yog ib lub sijhawm ntev tshaj plaws hauv highwell eps polystyrene styrofoam moulding tshuab manufacturers thiab cov neeg nyob hauv Suav teb. Nrog kev pab los ntawm cov khoom siv thiab cov cuab yeej siv siab, tag nrho peb cov khoom muaj nqi zoo thiab tsis tshua muaj nqes. Txais tos mus yuav cov pheej yig customized tshuab ntawm peb lub Hoobkas.
Qhov ua ntej:
1. Tswj cov PLC thiab cov npo kov, yooj yim rau kev khiav lag luam.
2. Nrog lub tshuab nqus tsev tsim cov khoom ceev ceev thiab txias, thaum lub sijhawm cov dej tsis zoo.
3. Muaj ntau hom tshuab pa tshuaj, nws tuaj yeem kov tau cov khoom tsis muaj pwm.
Yam ntxwv:
1. Lub tshuab no siv cov PLC thiab cov npo kov, cov txheej txheem siab molding thiab tuaj yeem tsim ntau yam qauv ntawm EPS cov khoom.
2. Lub cav no tuaj yeem muab ntau hom khoom ua npuas sib txawv nrog cov qis qis, qis ceev ceev thiab txo qis zog.
3. Muaj plaub hom kev khiav hauj lwm (automatic, semi-automatic, pause-startup thiab phau ntawv lag luam) nrog kev tiv thaiv kab mob kev tiv thaiv kom ruaj ntseg zoo.
4. Lub tshuab no muaj microcomputer tswj thiab kov zaub screen. Nws tuaj yeem ua haujlwm zoo nyob rau hauv kev tswj hwm kev tswj hwm computer thiab kev tswj hwm nrog kev sib koom tes nrog kev lag luam. Muaj peev xwm ntawm kev lag luam thiab yooj yim rau kev tswj hwm, nws tuaj yeem txo qhov kev siv zog.
5. Lub tshuab no siv cov hluav taws xob thiab kev sib txuas hydraulic siab zog, uas ua rau lub zog ceev ceev, txo kom lub zog siv zog thiab txo cov khoom muaj kuab paug.
6. Hom kev lag luam hauv Hydraulic.
Nco Ntsoov:
1. Pwm coated nrog Zinc yog xaiv tau
2. Kev ncua ntawm qhov siab ntawm qhov siv tshuab yog xaiv tau
3. Lwm qhov ntau thiab tsawg
Yam khoom | LWS-1200B | LWS-1400B | LWS-1600B | LWS-1750B | LWS-2200B | |
Pwm Dimension (hli) | 1200 * 1000 | 1400 * 1200 | 1600 * 1350 | 1750 * 1450 | 2200 * 1350 | |
Max Ua Rau Pej Xeem (hli) | 1050 * 850 * 350 | 1200 * 1050 * 350 | 1400 * 1200 * 350 | 1550 * 1300 * 350 | 200 * 1200 * 350 | |
Mob Stroke (hli) | 150 ~ 1350 | 150 ~ 1350 | 150 ~ 1350 | 150 ~ 1350 | 150 ~ 1350 | |
Chav | Nkag | DN65 | DN80 | DN100 | DN100 | DN100 |
Khoom Noj | 5 ~ 7kg / voj voog | 6 ~ 9kg / voj voog | 7 ~ 10kg / voj voog | 8 ~ 12kg / voj voog | 12 ~ 15kg / voj voog | |
Siab | 0.5 ~ 0.7Mpa | 0.5 ~ 0.7Mpa | 0.5 ~ 0.7Mpa | 0.5 ~ 0.7Mpa | 0.5 ~ 0.7Mpa | |
Dej Txias | Nkag | DN65 | DN80 | DN80 | DN80 | DN80 |
Khoom Noj | 45 ~ 130kg / lub voj voog | 50 ~ 150kg / voj voog | 55 ~ 170kg / lub voj voog | 55 ~ 180kg / voj voog | 60 ~ 190kg / lub voj voog | |
Siab | 0.3 ~ 0.5Mpa | 0.3 ~ 0.5Mpa | 0.3 ~ 0.5Mpa | 0.3 ~ 0.5Mpa | 0.3 ~ 0.5Mpa | |
Compressed Cua | Nkag | DN40 | DN50 | DN50 | DN50 | DN50 |
Khoom Noj | 1.5m 3 / voj voog | 1.8 m3 / voj voog | 2 m3 / voj voog | 2 m3 / voj voog | 2.5 m3 / voj voog | |
Siab | 0.5 ~ 0.7Mpa | 0.5 ~ 0.7Mpa | 0.5 ~ 0.7Mpa | 0.5 ~ 0.7Mpa | 0.5 ~ 0.7Mpa | |
Lub tshuab nqus tsev twj tso kua mis | 165m3 / h | 230m3 / h | 280m3 / h | 280m3 / h | 280m3 / h | |
Lub voj voog sijhawm | 60 ~ 100s | 70 ~ 140s | 80 ~ 150s | 80 ~ 150s | 100 ~ 150s | |
Lub zog | 10.6kw | 14.1kw | 16.5kw | 16.5kw | 20kw | |
Zuag Qhia Tag Nrho (hli) | 4500 * 1840 * 2900 | 4600 * 2140 * 3100 | 5000 * 2300 * 3400 | 5000 * 2450 * 3500 | 5000 * 3000 * 3500 | |
Tshuab Luj | 4500kg | 5000kg | 5800kg | 6200kg | 7000kg | |
Ntim & Shipping
Ntim: txheem exporting pob
Shippingport: shanghai / ningbo
Kev Pabcuam
1. Cov neeg tau txais txiaj ntsim, lav cov khoom siv kom zoo thiab teb cov lus nug cov lus nug txhua lub sij hawm thiab nyob qhov twg.
2. Customizing cov cav tov raws li cov neeg xav nug, xws li kev tsim, txawv hom khoom, xim txawv, muaj nuj nqi ntxiv, thiab lwm yam.
3. Cov kws tshawb fawb mus rau cov neeg ua hauj lwm 'lub koom haum hauv lub sij hawm rau kev teeb tsa, kev cob qhia thiab kev sim khoom.
4. Qhov chaw seem ntau yog muab rau cov neeg muas noj dawb los xyuas kom lub Hoobkas ua haujlwm tsis tas yuav nres.
5. 1 xyoo dawb warranty, Kev pab cuam lub neej tau txais kev pab.
Yog tias koj xav tau ib qho ntawm peb cov khoom los yog xav tau kev txhawb nqa los ntawm peb txog koj lub Hoobkas los yog lwm tus neeg, thov koj xav tiv tauj peb. Peb tab tom nrhiav rau pem hauv ntej kom txhim kho kom zoo thiab kev sib raug zoo nrog kev lag luam nrog cov neeg tuaj ntawm thoob plaws lub ntiaj teb.
